Vehicle Specifications

Engine

SpecificationValue
Engine Displacement106 cc
Engine typeAir cooled, 4 stroke
Number Of Cylinders1
Max Power7.5 Bhp @ 7500 rpm
Max Torque7.8 Nm @ 6000 rpm
StarterKick

Transmission

SpecificationValue
Transmission TypeManual
Number Of Speed Gears4
Final Drive(Rear Tyre)Chain

Wheels & Tyres

SpecificationValue
Front Tyre3.00x18
Rear Tyre3.00x18

Brakes

SpecificationValue
Front Brake130 mm Drum
Rear Brake130 mm Drum

Suspension

SpecificationValue
Front SuspensionTelescopic Hydraulic
Rear SuspensionSwing Arm Type, Coil Spring, Oil Damped

Dimensions

SpecificationValue
Length (Overall)2000 mm
Width (Overall)730 mm
Height (Overall)1050 mm
Wheelbase1290 mm
Ground Clearance173 mm
Kerb Weight130 kg
Fuel Capacity13.0 Litres
